- New
Model : DWP-FV-CPM158-1.00HP
Power : 750W 1HP
Rated Voltage / Frequency : 180-240V / 50Hz
RPM : 2850 RPM
Capacity : 20uf / 450v
Head Max :30m
Suction head : 8m
Water Flow Maximum (l/min) : 100L / min
Pipe Diameter in and out : 1"*1"25mm x 25mm
Impeller : SS304
Dimension L X W X H (mm): 335 * 200 * 262 mm
net weight : 11.75 kg
Motor Winding : 100% Copper
Projection Class : IP44
Insulation Class : F
Safety Standard Is According To IECF: IEC60335 - !; 2012 + A11:ICE55014-1:2021
Mechanical Seal :Silicon / Graphite / SS / NBR
Pump body / Front Cover : Cast iron HT200
Maximum Ambient Temperature : 40C
Max Voltage Drop : 180V
Fluid Temperature : 60C
